Which Brush Models Can WXD-4A010 Make?

General Introduction of CNC 4-Axis 4-Head Roller Brush Drilling Machine WXD-4A010

1) This WXD-4A010 is a 4-axis 4-head drilling machine, used to drill holes for small plastic/wood roller brushes. Please note that it drills holes only, operator needs to use another tufting machine to fill filaments on roller brush pieces.

2) It's equipped with 4 drilling-heads and 8 grippers holding 8 roller brush pieces on worktable. Under "Automatic Mode", it drills holes continually, non-stop, and its maximum drilling speed is 7 holes per second.

3) X-axis supports the left/right movements of its worktable, Y-axis supports the forward/backward movements of the worktable, while Z-axis and A-axis support the rotating movements of its grippers.

4) This WXD-4A010 is used to process small roller brushes (50mm Diameter x 100mm Length) only, however, all our brush making machines could be customized exactly according to customer's production requirements, so, please do not hesitate to contact us at chloe@brushmachine1.com or just leave a message on this page for any of your further questions or doubts, it'll be our great pleasure to get back to you with a professional solution.

Technical Parameters of CNC 4-Axis 4-Head Roller Brush Drilling Machine WXD-4A010

Maintenance of CNC 4-Axis 4-Head Roller Brush Drilling Machine WXD-4A010

1) Operator should often add lubrication oil to the working parts of this roller brush drilling machine, so as to decrease abrasion.

2) Operator should regularly check each part to see whether there is a loose screw, and please make sure to tighten it, if he finds a loose one.

3) Please keep guide rails and ballscrews clean, and make sure that there is no scrap sticking on them, so as not to decrease the precision.

4) Be sure that the electric box works under ventilative conditions; do not put this roller brush drilling machine under humid or high-temperature conditions; do not shake the electric box.

5) Please keep electric box far away from magnetic field, otherwise it will be probably out of control.

6) Be sure that all cables connect correctly. Red, blue and yellow cables connect with three-phase 380V wires, green cable connects with neutral wire, yellow-green cable connects with earth wire. Plugs are numbered as "1, 2, 3, 4 , 5", "1, 2, 3" are for 3-phase 380V wires, "4" is for neutral wire, "5" is for earth wire.

7) The working voltage should be stable, around AC380±10V; over-voltage will probably cause the ruin of electronics.

8) Do not knock at the touchable screen with hard articles, otherwise it'll decrease its sensibility or even break the screen. Do not drag wires rudely, either.

9) Please note that there is high-voltage electricity inside electric box. If it is out of order, only professional technicians are allowed to check and dismantle it. Non-professionals are prohibited to dismantle it, so as to avoid getting an electric shock and the ruin of data.
